Miniature, CCTV and thermal cameras, plus coaxial HD conversion, encoding, capture and test tools — dependable imaging hardware for integrators and OEMs.
Miniature imaging, coaxial HD conversion, encoding & capture and test tools — filter by interface and scenario.
Video Converter
HDMI sources up to 1080p convert to an AHD 1080p 25/30 stream on two BNC ports, one AHD output plus one loop-out, with a mirrored HDMI output. Runs on DC 5-12 V through a 2.1 mm jack.
Video Converter
Coaxial analog HD input up to 5MP in AHD, TVI or CVI converts to HDMI and VGA 1080p/60 plus NTSC/PAL CVBS, with a loop-through for the original DVR; coax runs to 300 m and stages cascade.
USB Camera
A 1/3-inch progressive CMOS with FH8852 processing delivers 1920x1080 over USB 2.0 via UVC and UAC to Windows, Android or Linux, with 3.6 mm or 4 mm M12 lenses and 0.05 Lux sensitivity.
Thermal Camera
Uncooled VOx infrared core above a 1/2.8-inch 2MP visible sensor runs global and zone temperature checks and captures 20 to 30 faces; HDMI output, FTP or HTTP upload, -20 C to 55 C.
Thermal Camera
256x192 infrared with 12 um pixels plus 2MP visible imaging measures -15 C to 150 C at +/-0.3 C accuracy, raising high, low and zone alarms on a 50,000-face library, ONVIF or GB28181.
Thermal Camera
An integrated blackbody reference anchors a 256x192 infrared core overlaid with 2MP visible video, logging 100,000 screening records on 16GB internal storage, HDMI output, IP64 housing.
Thermal Camera
Dual-lens Hisilicon channel head merges 30 C to 45 C screening at +/-0.3 C with liveness-checked face access: a 22,400-face library, matching under 500 ms, Wiegand 26/34 input and output.
Video Converter
Supports coaxial analog HD feeds up to 8MP alongside 3MP and 5MP, re-timed to HDMI and VGA at 1080p/60 plus CVBS with one live loop-through port; peak draw 4 W, net weight 185 g.
Assembly and inspection flow from sensor and lens to finished unit keeps batch consistency.
Pinhole lens, board and housing are designed in-house; miniature cameras go down to 30×30 mm.
AHD/TVI/CVI/CVBS coaxial and ONVIF network cameras run as two product lines, so hybrid retrofits ship from one supplier.
Image sensors, SoCs and lenses are inspected batch by batch, and every finished unit passes 48-hour burn-in and live-image testing.
Shipped to Europe, North America, the Middle East, Southeast Asia, Australia and Africa, with multi-language OSD and destination power standards.
New Products
Sensor configuration, temperature range and accuracy of the dual-spectrum thermometry camera, plus the on-site calibration steps and deployment notes for the blackbody version.
Company News
Batch preparation, 48 hours of power-on aging, live-image rechecks and nonconforming-unit handling at the Shenzhen plant, applied to small orders and returned repairs alike.
Company News
How the shipped CCTV testers work at coaxial and network points: multi-format image confirmation, coaxial control, cable checks and how the acceptance checklist is filled.
Industry News
Around bringing coaxial-to-IP and HDMI encoders into a recording host, this covers device discovery, stream retrieval, bitrate and frame-rate alignment and PTZ control order.
FAQ
Practical answers on coaxial HD installation: cable length and gauge, solder-free versus soldered BNC connectors, converter cascading and loop-out, tester steps, and HDMI-to-coax bands.
FAQ
Troubleshooting by observed symptom: one channel with no picture, rolling borders, night-time washout, close-range white-out, a missing DVR channel and a USB image that stalls.
Standards & Protocols
What separates PAL from NTSC in field frequency and frame rate, general mains habits by region, and the naming, pixel counts and bandwidth conversions of 720P, 960H, 1080P and higher bands.
Standards & Protocols
Protocols and stream addresses as labelled on cameras, encoders and control keyboards, with a check order for cross-vendor work, quantified acceptance figures and fault isolation.
Retail
A South China convenience chain moved from an 8-channel analog system to coaxial HD, fitting starlight miniature cameras at checkouts and the liquor cabinet while keeping the ceiling coax and testing every line first.
City & Campus
An office campus wired around 2008 kept its coax, swapped front ends to coaxial HD cameras, merged old channels through encoders, and retrofitted in three batches after testing every line first.
Retail
A 20-store East China chain added PoE camera points per store, bridged retained coax channels through encoders, capped uploads to 720P substreams, and let supervisors poll key channels by region.
Transport
A bus depot in Northwest China laid starlight IP cameras along its night perimeter and added dual-spectrum thermal units over the EV charging area, keeping trend records through encoders.
Manufacturing
Assembly lines at a Pearl River Delta equipment maker put miniature cameras in tight stations, judged defects through capture cards on the industrial PC, and pushed key station views to line-side displays.
Manufacturing
A food plant in Southern Jiangsu graded cameras by environment: IP68 models in wash-down areas, dual-spectrum thermal units in electrical and boiler rooms, and separate zoning for perimeter and workshops.
Share resolution, interface, power and mounting requirements, and we will recommend models with a quotation.
